Мултиметър Uni-T UT89X
Item 1 of 1
information
description:
Uni-T UT89X True RMS цифров мултиметър
Свойства
1. 1000V AC/DC； 20A AC/DC
2. True RMS, 6000 count
3. Dual range NCV test which quickly identifies neutral and live wires through light intensity
4. Audible/visual alarm
5. Capacitor charging indicator
6. Ergonomic design
7. Double injection molding
8. 1m drop proof
9. Flashlight; Auto backlight
| Specifications | Range | UT89X |
| DC voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.5%+2) |
| AC voltage (V) | 6V/60V/600V/1000V | ±(0.8%+5) |
| DC current (A) | 60μA/60mA/600mA/20A | ±(0.8%+8) |
| AC current (A) | 60mA/600mA/20A | ±(1%+12) |
| Resistance (Ω) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.8%+3) |
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF/100mF | ±(2.5%+20) |
| Frequency (Hz) | 9.999Hz/9.999MHz | ±(0.1%+4) |
| Duty cycle | 0.1%~99.9% | ±(2%+5) |
| Temperature (℃) | -40℃~1000℃ | ±(2%+4) |
| Temperature (℉) | -40℉~1832℉ | ±(2%+8) |
| Features | ||
| Display count | 6000 | |
| Sampling rate | 3 times/s | |
| True RMS | √ | |
| AC voltage frequency response | 45~1000Hz | |
| AC current frequency response | 45~1000Hz | |
| Live wire test | √ | |
| Audible/visual alarm | V/A/Cap/Diode/hFE/NCV/Live (UT89X)/LED (UT89XD) | |
| Diode/Continuity test | √ | |
| Transistor hFE | √ | |
| Dual range NCV test | √ | |
| Auto power off | √ | |
| Low battery indication | √ | |
| Data hold | √ | |
| Function selection | SELECT | √ |
| Flashlight | √ | |
| Auto backlight | √ | |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 4 | |
| Display | 61mm x 36mm | |
| Product color | Red and grey | |
| Product net weight | 345g | |
| Product size | 189mm x 89mm x 53mm | |
| Standard accessories | Batteries, test lead, k-type temperature probe | |
| Standard individual packing | Gift box, English manual | |
